Dig-Octa Brainboard-32-8L v4
What’s in the box?

Back to Brainboard-32-8L main

All boards in the Dig-Octa system come with several accessories included in the box. These vary from included connectors to parts needed to build a stack, etc..

• Brainboard-32-8L v4
  • Connectors
    • 1x 2p 3.81mm pluggable for power input
    • 1x 4p 3.81mm pluggable for button input
    • 2x 4p 3.81mm pluggable
      • 2x for LED connectors
  • Pigtails
    • 1x 3p JST PH to 3x wire for relay output
    • 1x 6p JST PHD to 6x female dupont for accessory add-ons
  • Standoffs and screws
    • 5x M2.5 3cm female-female for stack on top of powerboard
    • 5x M2.5 2cm male-female (with 6mm screw thread) for extra brainboard stack
    • 10x M2.5 6mm screws
