QuinLED An-Penta-Mini Pinout Guide Back to QuinLED An-Penta-Mini Index To be able to configure the QuinLED-An-Mini in your software of choice (like WLED or ESPhome) you are going to need to know what is connected to what pins. In the below table you can see exactly how all the hardware is connected internally. Product shots […]
QuinLED An-Penta-Mini Specifications Back to QuinLED An-Penta-Mini Index The QuinLED An-Mini was designed with keeping cost and a small form factor in mind dictating it’s design and features. Please see a list of it’s hardware features and capabilities below. Features Micro-Controller and Connectivity Based on the Espressif ESP32-C3 Micro-controller chip 2.4Ghz WiFi connection with […]
QuinLED An-Penta-Mini Back to QuinLED An-Penta Index Also visit the new dedicated website: https://an-penta.info ! The QuinLED An-Penta-Mini is designed to be a low entry compact Analog LED PWM dimmer while still retaining some advanced features vs generic offerings on the market. Some of these include: 5x PWM LED output channel (up to RGBCCT) External […]
QuinLED-An-Penta-DIY Back to Analog LEDs section DIY version renamed to QuinLED-An-Penta-DIY! The QuinLED-An-Penta is an Analog LED dimmer/controller board which uses an ESP32 and PWM to control 5 LED channels. It’s built with high power handling for total and per channel in mind and does everything “the right way” including 12v MOSFET gate drivers, 2x […]
QuinLED-An-DecaPenta ESPhome Example configs WORK IN PROGRESS! substitutions: esphome_name: preprod-decapenta-1 esphome: name: ${esphome_name} esp32: board: mhetesp32devkit #framework: # type: esp-idf # version: latest # variant: ESP32C3 wifi: ssid: !secret wifi_ssid password: !secret wifi_password use_address: 10.24.1.126 web_server: #Disable logging/UART logger: # level: NONE baud_rate: 0 i2c: sda: 15 scl: 16 #frequency: 50kHz scan: true api: reboot_timeout: […]
